Spiral Point Taps-Plug Style
Welcome to our factory! Get high-quality Spiral Point Taps-Plug Style directly from the manufacturer. Shop now for precision and durability.
Request a Quote

PRODUCTS DETAILS

Basic Info.

HS Code
8207400000
Production Capacity
50000PCS Per Year

Product Description

SPIRAL POINT TAPS-PLUG STYLE
Ground Thread, High Speed Steel

Size No. Of
Flute		 H
Limit		 Model No. Size No. Of
Flute		 H
Limit		 Model No.
0-80NF 2 H-1 311-9002 5/16"-18NC 2 H-5 311-9090
0-80NF 2 H-2 311-9004 5/16"-18NC 3 H-2 311-9092
1-64NC 2 H-1 311-9006 5/16"-18NC 3 H-3 311-9094
1-64NC 2 H-2 311-9008 5/16"-18NC 3 H-5 311-9096
1-72NF 2 H-1 311-9010 5/16"-24NF 2 H2 311-9098
1-72NF 2 H-2 311-9012 5/16"-24NF 2 H3 311-9100
2-56NC 2 H-2 311-9014 5/16"-24NF 3 H3 311-9102
2-64NF 2 H-2 311-9016 3/8"-16NC 3 H2 311-9104
3-48NC 2 H-2 311-9018 3/8"-16NC 3 H3 311-9106
3-56NF 2 H-2 311-9020 3/8"-16NC 3 H5 311-9108
4-40NC 2 H-2 311-9022 3/8"-24NF 3 H2 311-9110
4-40NC 2 H-7 311-9024 3/8"-24NF 3 H3 311-9112
4-48NF 2 H-2 311-9026 7/16"-14NC 3 H3 311-9114
5-40NC 2 H-2 311-9028 7/16"-14NC 3 H5 311-9116
5-40NC 2 H-7 311-9030 7/16"-20NF 3 H3 311-9118
5-44NF 2 H-2 311-9032 7/16"-20NF 3 H5 311-9120
6-32NC 2 H-2 311-9034 1/2"-13NC 3 H3 311-9122
6-32NC 2 H-3 311-9036 1/2"-13NC 3 H5 311-9124
6-32NC 2 H-7 311-9038 1/2"-20NF 3 H3 311-9126
6-40NF 2 H-2 311-9040 1/2"-20NF 3 H5 311-9128
8-32NC 2 H-2 311-9042 9/16"-12NC 3 H3 311-9130
8-32NC 2 H-3 311-9044 9/16"-12NC 3 H5 311-9132
8-32NC 2 H-7 311-9046 9/16"-18NF 3 H3 311-9134
8-36NF 2 H-2 311-9048 9/16"-18NF 3 H5 311-9136
10-24NC 2 H-2 311-9050 5/8"-11NC 3 H3 311-9138
10-24NC 2 H-3 311-9052 5/8"-11NC 3 H5 311-9140
10-24NC 2 H-7 311-9054 5/8"-18NF 3 H3 311-9142
10-32NF 2 H-2 311-9056 5/8"-18NF 3 H5 311-9144
10-32NF 2 H-3 311-9058 11/16"-11NS 3 H3 311-9146
10-32NF 2 H-7 311-9060 11/16"-16NS 3 H3 311-9148
12-24NC 2 H-3 311-9062 3/4"-10NC 3 H3 311-9150
12-28NF 2 H-3 311-9064 3/4"-10NC 3 H5 311-9152
1/4"-20NC 2 H-2 311-9066 3/4"-16NF 3 H3 311-9154
1/4"-20NC 2 H-3 311-9068 3/4"-16NF 3 H5 311-9156
1/4"-20NC 2 H-5 311-9070 7/8"-9NC 3 H4 311-9158
1/4"-20NC 3 H-2 311-9072 7/8"-9NC 4 H4 311-9160
1/4"-20NC 3 H-3 311-9074 7/8"-14NF 3 H4 311-9162
1/4"-20NC 3 H-5 311-9076 7/8"-14NF 4 H4 311-9164
1/4"-28NF 2 H-2 311-9078 1"-8NC 3 H4 311-9166
1/4"-28NF 2 H-3 311-9080 1"-8NC 4 H4 311-9168
1/4"-28NF 3 H-2 311-9082 1"-12NF 4 H4 311-9170
1/4"-28NF 3 H-3 311-9084 1"-14NS 4 H4 311-9172
5/16"-18NC 2 H-2 311-9086 1"-12NF 3 H4 311-9174
5/16"-18NC 2 H-3 311-9088 1"-14NS 3 H4 311-9176
Spiral Point Taps-Plug Style
Spiral Point Taps-Plug Style Spiral Point Taps-Plug Style Spiral Point Taps-Plug Style Spiral Point Taps-Plug Style Spiral Point Taps-Plug Style
