Basic Info.
Model NO.
single flute cutter
Structure
Integral
Material
Tungsten Steel
Type
Cylindrical Milling Cutter
Condition
New
Transport Package
Plastic Box + Cartoon
Specification
SGS
Trademark
Hiboo
Origin
Changzhou Jiangsu China
HS Code
8207709000
Production Capacity
50000PCS/Mouth
Packaging & Delivery
Package Size
35.00cm * 18.00cm * 15.00cm
Package Gross Weight
0.080kg
Product Description
| Tool models | End mill, Drill Bits, Reamers, Boring cutters, Taps, Saw Blades, Welding Tools, Customized Cutting Tools, etc. |
| Raw Material | Solid carbide, Tungsten carbide (Customized) |
| Coating | TIN, TiALN, AlTiN, TiAIN, etc. |
| Length | 30-200mm (Customized) |
| Diameter | 3mm-40mm (Customized) |
| HRC | 45/55/60/65 Degrees |
| Controlling mode | CNC |
| Usage | General High Speed Cutting Used On CNC Lathe Used in industrial milling applications such as profile milling, tracer milling, face milling, and plunging |
| Processing material | Alloy steel, titanium alloy, nickel base alloy, steel, stainless steel, quenched and tempered hardened steel, non-ferrous metals, etc. |
| Application | Automotive, aviation, aerospace enterprise, motorcycle engine, diesel engine, carburetor, compressor, mold industry, etc. |
Customized Available,OEM or ODM Available
1. Raw Material
| HRC45 | HRC55 | HRC60 | HRC65 |
| Grain Size:0.7um Co:10 % Flexural strength: 3320N/mm2 | Grain Size:0.6um Co:10 % Flexural strength: 4000N/mm2 | Grain Size:0.5um Co:12 % Flexural strength: 4300N/mm2 | Grain Size:0.4um Co:12.5 % Flexural strength: 4300N/mm2 |
2. Made by All Imported CNC Grinding Machines , which from Australia, German, TaiWan .
3. Each end mill is inspected by Zoller measuring and inspected machine.
4. The following Specification for your refer, We also provide the OEM or ODM service
| Specifications | |||
| Diameter(d) Radius(R) | Cutter length(l) | Overall length(L) | Shank diameter(D) |
| ∮1 | 3 | 50 | ∮4 |
| ∮1.5 | 4 | 50 | ∮4 |
| ∮2 | 6 | 50 | ∮4 |
| ∮2.5 | 8 | 50 | ∮4 |
| ∮3 | 8 | 50 | ∮4 |
| ∮3.5 | 10 | 50 | ∮4 |
| ∮4 | 11 | 50 | ∮4 |
| ∮4 | 15 | 75 | ∮4 |
| ∮4 | 20 | 100 | ∮4 |
| ∮4.5 | 13 | 50 | ∮6 |
| ∮5 | 13 | 50 | ∮6 |
| ∮5 | 20 | 75 | ∮6 |
| ∮5 | 30 | 100 | ∮6 |
| ∮5.5 | 15 | 50 | ∮6 |
| ∮6 | 15 | 50 | ∮6 |
| ∮6 | 20 | 75 | ∮6 |
| ∮6 | 30 | 100 | ∮6 |
| ∮6 | 20 | 60 | ∮8 |
| ∮8 | 20 | 60 | ∮8 |
| ∮8 | 25 | 75 | ∮8 |
| ∮8 | 35 | 100 | ∮8 |
| ∮9 | 25 | 75 | ∮10 |
| ∮10 | 25 | 75 | ∮10 |
| ∮10 | 40 | 100 | ∮10 |
| ∮11 | 30 | 75 | ∮12 |
| ∮12 | 30 | 75 | ∮12 |
| ∮12 | 45 | 100 | ∮12 |
| ∮14 | 35 | 100 | ∮14 |
| ∮16 | 40 | 100 | ∮16 |
| ∮18 | 45 | 100 | ∮18 |
| ∮20 | 45 | 100 | ∮20 |
| Notes:If there are special requirements,can be customized. | |||
5.Suit the automotive parts and engines, motorcycles, and bicycle industries and other Aluminum Processing Industrial.
6. Package and shipping details
Laser brand on the cutter's shank , 1 pc in a plastic tube , 10pcs a group
7.Delivery Time
For samples , we dispatch your tools in 2-7 workdays .
For formal orders,We delivery tools to you in 7-30 workdays , it will depond on your order quantity .
