Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table
Get the Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table from our factory. Built for precision and stability in optical experiments.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
POT-P Series
Surfaced Roughness
≤0.8μm,Matt Surface Treatment
Mounting Holes
M6 or Imperial
Tapped Holes
on 25mm Grid
Load Capacity
100~2000kgs
Capacity
1000sets Per Month
Transport Package
Plywood and Carton
Specification
different size and volume
Trademark
LSXPT
Origin
Nanchang, Jiangxi
HS Code
9031809090
Production Capacity
300 Sets /Month

Product Description

POT-P Series Solid Honeycomb Core Anti-Vibration Optical Table



Breadboard:

- High density Honeycomb core structure

- Surface Roughness: 0.8-1.6μm

- Flatness/Unevenness: 0.02-0.05mm

- Inherent Frequency: 1.5-2Hz

- Amplitude: <1μm

- Mounting Holes: M6 tapped holes on 25mm grid. Hole to edge 12.5mm or 37.5mm.

- Top Skin: 5mm Bottom Skin: 4mm

- Material: Stainless Steel.


Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table

Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table


Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table




Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table

Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table
Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table
Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table
Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table Pot-P Series Solid Vibration Isolation Honeycomb Core Optical Table
