Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine

Shop the Mr. Nhv-130A Hydraulic Quick Action Precision Milling Vise for CNC Machine at our factory for reliable and efficient machining operations.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
MR- NHV- 130A
Transport Package
Exporting Package, One Machine in a Plywood Case
Specification
Weight: 40kg
Trademark
MRCM
Origin
Zhejiang, China (Mainland)
Production Capacity
100 Set/Sets Per Day

Product Description

Product Description
Mechanical/ Hydraulic spindle without original clutch mechanism
Rigid material-vise body of ductile iron FCD60JIS(Equal to
GGG60) with 60kgs/mm or 80,000psi tensile strength.
Vise bed flame hardened to HRC45°and takes up wear and maintain accuracy for long



Model: MR- NHV- 130A
Drive Mode Manual
Metial  Spheroidal graphite cast iron
Hardness HRC 52-60
Parallelism Whthin 0.003mm/100mm
Squareness Within 0.005mm/100mm
Precision 0.008mm
Machine Type Grinding Machine
Package Canton

Specification

MR- NHV- 130A


        High power type omnibearing precision pressure vice, suitable for general milling machine, CNC vertical
comprehensive processing machine, the largest opening can clamp 300mm. Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine

Unit: mm

Mode A B C D E F G H J K L M Clamping force Weight
NHV-130A 529 195 121 224 130 19 134 16 0-210 52 310 18 40KN 38KG
NHV-150A 620 210 136 224 130 19 134 16 0-300 52 310 18 50KN 58KG
NHV-130B 670 185 117 185 165 19 118 16 0-320 46 310 18 35KN 36KG
NHV-160B 800 247 125 240 200 19 133 16 0-300 51 310 18 45KN 57KG
NHV-200B 900 266 165 280 240   162   0-300 62     55KN 93K

Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine

Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine
Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine
Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine
Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine
Packaging & Shipping
   EXPORTING PACKAGE, SAFE AND STABLE

Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine

Company Information
MRCM is a manufacturer specialized in developing and producing small special-purpose tool grinders, precision machinery
 tools. It is a high-tech enterprise which includes research and development; design; production; sale; and after-sale service. In the past many years, we've been committed to research, develop and produce the grinding tools. We've been
 started from the portable drill bit sharpener and continuously developed to the current four-axis and six-axis CNC tool grinding machine. The CNC machine with different functions to meet the market requirements, effectively improve
the working life of tools and reduce production costs.
Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine


Main products include: CNC tool grinder, drill bit sharpener, end mill sharpener, screw tap sharpener, lathe tool grinder,
saw blade sharpener, universal cutter grinder, universal tool grinder, chamfer, tapping machine, vise, sucker, zero
positioning, and so on.

Engaged in international marketing, participated in international exhibitions, such as EMO Hannover, cooperated with the
domestic and foreign companies. We've passed the CE, ISO 9001 certification, have been applied for over 70 national
patents, sold product to 60 countries and regions, 80% of exporting products are sold to developed countries such as
Japan, Europe countries and so on.
  Mr- Nhv- 130A Hydraulic Quick Action Precision Milling Vise for CNC Machine


FAQ
 1.What is your advance?
A:(1)We have ourselves factory. We accept the order if you want to customize products or design the product.
(2)Professional website platform and one-to-one online service.
(3)Various products in low MOQ and competitive prices.
(4)We have a strong R&D team and now we have 52 patents products.
(5)80% exporting products have been sold to Europe,America and Japan, high quality.
2. What's the minimum order quantity?
A: One set is acceptable
3. How about the payment Term?
A: We accept T/T,Western Union,LC
4. What's your port?
A: Ningbo/Shanghai.
5. Can we use our own shipping agent?
A: Yes,you can. we had cooperated with many forwarders.If you need,We can recommend some forwarders to you and you can
compare the price and the service.
6. Can we use our own LOGO or design for sticker?
A: Yes,you can contact with the salesman. And sent us more details about the LOGO or sticker.
7. How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to quantity.
8. Do you provide samples? Is it free or extra ?
A: Yes, we could offer the sample for cheaper price but do not pay the cost of freight.
