Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set

Find high-quality Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set at our factory. All taps are precision-made for efficient threading." Note: The SEO description provided is 156 characters long.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • FAQ
Overview

Basic Info.

Model NO.
DS Tap
Application
Motorize, Manual
Customized
Customized
Flute Type
Spiral Flute/Spiral Point/Straight Flute
Materials
HSS
HSS
65~66HRC
Delivery Time
3-7 Days
Transport Package
Hard Carton Box
Specification
M1-M68
Trademark
DS
Origin
China
HS Code
82074000
Production Capacity
100000/Month

Packaging & Delivery

Package Size
20.00cm * 10.00cm * 10.00cm
Package Gross Weight
1.000kg

Product Description

Product Description





Details of HSS Machine Taps:

  • High hardness, fast cutting, wear high temperature.
  • Spiral groove is conducive to remove crumbs, not easily broken tap.
  • Spiral Tap the crumbs into a spiral up chip evacuation, it is more suitable for the processing of blind holes and
  • sticky materials processing.

Features of HSS Machine Taps:

1. High hardness, fast cutting, wear high temperature.
2. Spiral groove is conducive to remove crumbs, not easily broken tap.
3. Tap the crumbs into a spiral up chip evacuation, it is more suitable for the processing of blind holes and sticky materials processing.

Details of HSS Machine Taps:

  • High hardness, fast cutting, wear high temperature.
  • Spiral groove is conducive to remove crumbs, not easily broken tap.
  • Spiral Tap the crumbs into a spiral up chip evacuation, it is more suitable for the processing of blind holes and
  • sticky materials processing.

Features of HSS Machine Taps:

1. High hardness, fast cutting, wear high temperature.
2. Spiral groove is conducive to remove crumbs, not easily broken tap.
3. Tap the crumbs into a spiral up chip evacuation, it is more suitable for the processing of blind holes and sticky materials processing.



SIZE OVERALL LENGTH THREAD LENGTH
M2*0.4 41 8.0
M2.2*0.45 44.5 9.5
M2.5*0.45 44.5 9.5
M3*0.5 48 11.0
M3.5*0.6 50 13.0
M4*0.7 53 13.0
M5*0.8 58 16.0
M5.5*0.9 62 17.0
M6*1 66 19.0
M7*1 66 19.0
M8*1.25 72 22.0
M9*1.25 72 22.0
M10*1.5 80 24.0
M11*1.5 85 25.0
M12*1.75 89 29.0
M14*2 95 30.0
M16*2 102 32.0
M18*2.5 112 37.0
M20*2.5 112 37.0
M22*2.5 118 38.0
M24*3 130 45.0
M27*3 135 45.0
M30*3.5 138 45.0
M33*3.5 151 51.0
M36*4 162 57.0
M39*4 170 60.0
M42*4.5 187 67.0
M45*4.5 187 67.0
M48*4 187 67.0
M52*5 200 70.0
M56*5.5 200 70.0
M60*5.5 221 76.0
M64*6 224 79.0
M68*6 234 79.0
Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set Metric Thread Metric Plug Tap Machine Hand Screw Thread Taps Set
FAQ

Q: Are you trading company or manufacturer ?
A: We are professional manufacturer,have more than 15 years experience in this field.

Q: Is free shipping possible?
A: We don't offer free shipping service,but we will give you some discount if you buy large quantity products.
And we have cooperation Express Companies,can offer you the best price of shipping cost.

Q: Can you send products to our Forwarder in China?
A: Yes,if you have Forwarder in China,we will glad to send products to him/her.

Q: Can you produce Special carbide Tools ?
A: Yes We can. From 2013 year. Our factory main market change from standard end mills to special tools. Special tools according to
your drawing and sample.
