Medium/Heavy Load Hexagon Flange/Washer Nut Hammer Set Pin Drive Expansion Anchor

Hexagon Flange Nut Hammer Set Pin Drive Expansion Anchor - Premium quality products manufactured in our factory. Shop now for reliable and durable hardware.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
M-HDAB007
Application
Machinery, Chemical Industry, Environmental, Building, Concrete
Finish
Color-Zinc Plated
Material Type
Carbon Steel/Alloy Steel/Stainless Steel
Material Grade
Q215/Q235/1022/1035/A2/A4/304/316/410
Surface Treatment
Yellow/Blue/Clear/Color/HDG Zinc Plated
Embedment Length
40mm~250mm 11/2"~10"
Size Unit
Inch Size/ Metric Size
Washer/Nut
Flange Nut/Washer Nut Combined
Anchor Bolt Standard
GB /T 22795
Application for
Construction Building Concrete Cement Masonry Lift
Sample Policy
Samples in Stock Are Free with Freight Charged
Custom-Order
Customization by Drawing/Sample
Other Name
Hammer-Set Anchor, Nail in Anchor, Core-Strike Anc
Price Terms
EXW/Fob/CFR/CIF/DDP
Shipping/Delivery
Shipping/Delivery Production 25~35 Days/in Stock
OEM/ODM
OEM/ODM Available
Supplier Status
Factory Manufacturer Wholesaler
Transport Package
Polywoven Bag/Carton Box Palletizing/Customized PA
Specification
M6~M30 1/4"~1 1/4"
Trademark
Hilow
Origin
China
HS Code
7318150000
Production Capacity
1000K PCS/Month

Product Description

Medium/Heavy Load Hexagon Flange/Washer Nut Hammer Set Pin Drive Expansion Anchor

  Hammer Drive Anchor Bolt

Type: Hammer Drive Anchor
Definition: The Hammer Drive Anchor, also called Hammer-Set anchor, is a mechanical drive anchor consisting of a zinc die cast expansion body and zinc plated steel expander drive pin. Hammer-Set anchors are medium-duty anchors designed for a variety of fastening applications in concrete, block and brick.
Description: Hammer drive anchors are used for light duty fastening. They are best suited for installation in dry, indoor environments. They are not the best choice for use in damp or outdoor conditions. They should also not be used for overhead installation projects.
Application: What is a hammer drive anchor used for?
Hammer Drive Anchors can be used in concrete, brick and block base materials, and are best suited for light duty fastening. Hammer Drive Anchors are available in 3/16" and 1/4" diameters, and up to 3" long. The hole diameter required for a Hammer Drive Anchor is equal to the diameter of the anchor.
Others: How to use hammer drive anchors?
Clean out the hole of all debris. Insert the anchor through the hole in the fixture and into the hole in the base material. Using a hammer, hit the nail into the hammer drive anchor until the head is flush with the top of the anchor.
What is another name of Hammer Drive Anchor?
Hammer-Set anchor, Nail in Anchor, Core-Strike Anchor, Core Expansion Anchor, Hammer Hit Anchor, Hit Nail Expansion
Feel Free to contact us if you have any questions.
