Cold Forging, Heading, Stamping Solid Carbide Dies with High Quality

Product Name: Precision ForgePro Dies We are a factory specializing in cold forging, heading, and stamping solid carbide dies with high quality. Buy our top-notch precision dies now!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Application
Metal Machining and Wear Parts
Certification
ISO
Customized
Per Your Requirement
Features
Wear-Resisting Long Life
Service
Customize ODM OEM
Advantage
High Rigidity & Durable
Grade
K10/K20/K30/K40/Yl10.2/Yg6/Yg6X/Yg8/Yg10X/Yl10.2
Surface Finishing
Polished and Unpolished
Grain Sizes Selection
Ultra Fine, Fine, Medium, Coarse
Cobalt Percentage
From 3% to 30% Based on Different Grades
Wc+Co Powder
100% Virgin Material
Transport Package
Standard Package / Customize Packing
Specification
1-300 mm for Length, Width and Thickness
Trademark
Aseeder
Origin
China
HS Code
848190
Production Capacity
60 Tons Per Month

Product Description

SEED is the leading manufacturer and exporter of tungsten carbide components,  Nozzles radial bearings, as well as provide machining service and hardfacing processes based in China, with a branch office set up in Houston dedicated for North American's market in sales and customer support, we are able to manufacturing all kinds of tungsten carbide parts ( including carbide  dies )and wear parts based on your drawing and material specification requirement for difference industry application.

Cold Forging, Heading, Stamping Solid Carbide Dies with High Quality
 Features:

  1. High stability, long lifespan circle.
  2. Customized as your requirements.
  3. Approved factory for oil and natural gas industry TOP5 customers.
  4. With ASP9100 certificate , API certificate, ISO9001:2015
  5. With a Special Thread Processing Workshop

Cold Forging, Heading, Stamping Solid Carbide Dies with High Quality


Equivalent grade

ISO grade

WC%

Co%

Hardness (HRA±0.5)

Density (g/cm3±0.1)
TRS
Characteristics and Application
Mps
Min

YG6X

K01

94

6

93

14.85

2700
The fine grain size, suitable for processing of non- ferrous metal finishing and woodworking cutting
tools.
YG10X K20 90 10 92 14.45 3400 suitable for all kinds of milling cutter and hole machining tool.
YG13X K20 86.5 13.5 90.5 14 3500 excellent abrasion resistance and toughness, suitable for carpenter's tools.
YG4 K02 96 4 92.5 15.15 2300 suitable for high hard finishing of grey cast iron.
YG6A K10 94 6 92 14.95 2450 suitable for wire drawing die and woodworking cutting tools.
YG6X K10 94 6 91.5 14.95 2500 applies to non-ferrous metal cutting.
YG6 K20 94 6 91 14.95 2600 Used for rough machining of non-ferrous metals.
YG8 K30 92 8 90 14.7 2700 suitable for wire drawing die, drawing die.
YG9 K40 91 9 89 14.6 2800 suitable for processing hard low grey cast iron.
YG11 K40 89 11 88.5 14.45 2900 suitable for wearing parts and mining tools.
YG12 K40 88 12 89 14.4 3000 suitable for rough machining of non-ferrous metals.
YG13 K40 87 13 88.5 14.2 3100 suitable for wear resistance and resistance to stamping parts

Cold Forging, Heading, Stamping Solid Carbide Dies with High Quality
Recommend grade list of Carbide Plate & Strip:
The grades which used more frequently are YG8, YG15, YG20, YG10.2, YG2T, YG10X etc.Other grades can be offered according to customers' requirements. Afterwards the board can be broken out from the panel.


Grade ISO Grade COBALT CONTENT DENSITY HARDNESS TRS
% g/cm³ HRA N/mm²
K10T K05-K10 4.5-6.0 14.95-15.05 92.7 1800
YG8 K30 8 14.80 89.5 2200
YG6 K20 6 14.95 90.5 1900
YG6X K10 6 14.95 91.5 1800
YL10.2 K30 10 14.50 91.8 2400
YG13X K30-K40 13 14.30 89.5 2600
YG15 K40 15 14.00 87.5 2800
YL20.8 K40 15 14.00 88.5 3800

Major Product Lines

-->  Wear resistant carbide components via powder metallurgy technique

-->  Hardfacing (oxy-acetylene spray, PTA, HVOF, etc.) and surface enhancement (phosphating, boronizing, etc.)

-->  High-precision machining of metals (S.Steel, carbon steel, Inconel 718, etc.)

-->  Additive manufacture
